technique solution
solution ：
products processing solution
1> customer: 2> product: 3> material:
4> the product profile
5> machining accuracy: completely follow up the customer’s drawing;
6> work tool and fixture: 6” hydraulic chuck
7> the technique remarks: the program will set up the tools life-time management (customer pre-set
up the q’ty of the machining products, when reach it, automatically warning, for reducing the products
scraps and the toolsdamage.)
8> gongtie company will do the best to provide the technique guidance for cnc lathes and related
suggestion of the products processing technology.
|
cnc lathe the first process--- products fixture method and process proposal |
|||||
|
machining process 1> head, od(rough turning); 2> head, od fine turning; 3> id rough turning; 4> id fine turning; |
|||||
|
process |
tools |
process speed(r/min) |
traverse (mm/r) |
cycle time(s) |
|
|
head, od(rough turning) |
|
s1400 |
f0.12 |
≈15s |
0.7s |
|
head, od fine turning |
|
s1700 |
f0.1 |
≈15.5s |
0.7s |
|
id rough turning |
|
s1500 |
f0.11 |
≈9.5s |
0.7s |
|
id fine turning |
|
s1700 |
f0.08 |
≈11s |
0.7s |
|
total machining time≈54s |
|||||
|
feeding materials air blowing≈10s |
|||||
|
total time≈64s |
|||||
|
cnc lathe the second process--- products fixture method and process proposal |
|||||
|
machining process 1> head, step, od(rough turning); 2> head, step, od fine turning; 3>id fine turning; |
|||||
|
process |
tools |
process speed(r/min) |
traverse (mm/r) |
cycle time(s) |
|
|
head, step, od(rough turning) |
|
s1500 |
f0.1 |
≈12s |
0.7s |
|
head, step, od fine turning |
|
s1700 |
f0.08 |
≈12.5s |
0.7s |
|
id fine turning |
|
s1400 |
f0.08 |
≈10.5s |
0.7s |
|
total machining time≈38s |
|||||
|
feeding materials air blowing≈10s |
|||||
|
total time≈48s |
|||||
9) proposal cnc lathe：s36 8 station rotary workstock
9.1) cnc lathe: precise linear guide-way cnc lathe flat bed : s36
9.2) auto-loading/unloading system: gantry loader in 8 station rotary workstock
cnc lathe: precise linear guide-way cnc lathe flat bed : s36
auto-loading/unloading system: gantry loader in 8 station rotary workstoc
remarks:
with the 8 station rotary workstock, can put 95 blanks
11> parameters:
|
main parameters |
unit |
s36 |
q7 |
|
|
capability |
max. swing diameter |
mm |
460/120 |
400/98 |
|
max. turning length |
mm |
325/270 |
300 |
|
|
max. bar through-hole |
mm |
25（35） |
26（35） |
|
|
axis stroke |
x-axis travel |
mm |
420 |
320 |
|
z-axis travel |
mm |
345 |
315 |
|
|
rapid traverse |
x/z-axis |
m/min |
20 |
20 |
|
spindle |
spindle nose size |
n/a |
a2-5 |
a2-5 |
|
spindle hole through diameter |
mm |
48 |
48 |
|
|
spindle servo motor power |
kw |
(asynchronous )5.5/7.5 |
(asynchronous )3.7/5.5 |
|
|
spindle speed range |
rpm |
0～5000 |
0～5000 |
|
|
work piece clamping method |
n/a |
homemade collet |
homemade collet |
|
|
toolholder |
number of tools |
pcs |
5 |
5 |
|
toolholder type |
n/a |
t-slot blade row |
dovetail row of knives |
|
|
opt |
t-slot blade row live tool |
t-slot blade row live tool |
||
|
|
opt |
t-slot blade row 63 turret |
|
|
|
opt |
t-slot blade row 63turret live tool |
|
||
|
toolholder center height in radial |
mm |
62 |
50 |
|
|
tool size |
mm |
20*20 |
16*16 |
|
|
boring rod diameter |
mm |
25 |
25 |
|
|
|
||||
